Specification

Model

BKR23615HSB

Voltage (nominal)

36V

capacity

15Ah

energy

540Wh

theoretical range with usual usage

60-80km

cell

NCM18650

internal resistance

160mΩ

Minimum capacity

14.5Ah

Standard charge

Constant current 2A Constant voltage 42V, 200mA cut-off

standard discharge

Constant current 6.25A, final voltage 28V

cycles

500,> 60% capacity

Max. Charge current

4A

Max. Discharge current

15A

USB output

-

Charging temperature

0-45℃

Operating temperatur

0-60℃

storage

Temperature 15-35℃ at humidity 45-75%

Dimensions

Battery Dimensions:
Length x Width x Height
360 x 160 x 70 mm

storage

Dimensions

total weight

Luggage carrier dimensions (GM):
440 x 190 x 430 mm

≈6.45kg

charger

included (2A charging current)

Suitable for the following bike type/models

  • NCM Hamburg
  • NCM Munich

Package Includes:

  • 1x Battery

(R3S-3615A_Temp)

SKU R3S-3615A_Temp
Brand DAS-KIT
Shipping Weight 3.7000kg
Shipping Width 0.100m
Shipping Height 0.170m
Shipping Length 0.420m
Shipping Cubic 0.007140000m3
Unit Of Measure ea
Type Spare parts
