NCM M7


Introduction

An e-mountain bike equipped with high-end brakes, drive systems, and torque the NCM M7 is for adventurous riders who want to hit the trails comfortable in the knowledge that their e-bike can handle whatever they throw at it. Fitted with a location tag within the battery, feel safe knowing your e-bike is just a convenient check away.


Key Features

  • Ergonomic bicycle Grips
  • Comfortable sitting posture
  • All important controls are easily accessible
  • Supplied with 48V to deliver a high-output power
  • Built-in GPS (Battery Tag Technology)
  • Over 912Wh capacity for a longer distance
  • Up to 180 km Battery Range (depending on the conditions)
  • Up to 500W Peak Motor Power
  • Battery integrated into the frame for better aesthetics
  • Easily removable battery so you can charge it anywhere
  • A built-in USB port with 5V to charge mobile phones

Hydraulic Brakes

Das-Kit C8 Display

48V 19Ah Battery

Schwalbe Tyres

Specifications

  M7 Moscow Plus Moscow M3
Motor

Das-Kit X15 motor, 48V 250W,
500W Peak Power, max speed 25 km/h

 Das-Kit X15 motor, 48V 250W,
500W Peak Power, max speed 25 km/h		 Das-Kit X15 motor, 48V 250W,
500W Peak Power, max speed 25 km/h
Battery DEHAWK, I7, 48V 19Ah, 912Wh
with TAG Technology & USB Port		 DEHAWK, I5, 48V 16Ah, 768Wh with USB Port Das-Kit, I6, 48V 12Ah, 576Wh
Display Das-Kit C8 Advanced, LCD Display Das-Kit C7 Advanced, LCD Display Das-Kit L7, LCD Display
Charger Das-Kit, DK483, 48V 3A Fast Charger SANS 48V 2A Das-Kit, 48V 2A
Frame Alu. 6061, 27.5*480MM Alu. 6061, 19/20*480/510MM Alu. 6061 26"*460MM | 27.5"*480MM | 29"*520MM
Forks RST, OMEGA-TNL-27.5, with Hydraulic Lock System SUNTOUR XCM SUNTOUR XCT
Braking System Das-Kit, Hydraulic Disc Brakes Tektro Hydraulic Disc Tektro Disc
Gear Selector Shimano Altus 8 speed Shimano Acera 8 speed Shimano Altus 7 speed
Front Derailleur / Shimano Acera Triple Shimano Altus Triple
Rear derailleur Shimano, Acera, RD-M360 Shimano Acera, 8 speed Shimano Altus, 7 speed
Saddle Selle Royal, Lookin-A200UR, Black Selle Royal, Lookin-A200UR, Black NCM Velo, VL-3410
Tyre CST / Schwalbe, Smart Sam 27.5×2.35 CST / Schwalbe, Smart Sam 27.5×2.25 CST / Arisun Mount Cronos
Handle Grips Promax, HB-3188, Width 680mm, Sand Black Velo, VLG-1189D3 139mm Velo, VLG-1189D3
Pedal Wellgo, B087 Wellgo, B087 Wellgo, B087
Range Up to 180 km Up to 150 km Up to 110 km
Weight 27.3kg 28/29kg 25 kg


Sizing Chart

CM   A B C D E F
  Stand Over Height Wheel Base Frame Size Min / Max Seat Height Reach Overall Length
NCM M7 27.5"  Medium 170-185 82 110 48 87-105 39.8 181.3


Warranty

  • 1 year warranty on all electronic parts (including battery, motor, controller, display, and lights)
  • 2 year warranty on the bike frame. For more warranty information visit our FAQS.
  • Apart from manufacture defects that could be present, parts that wear due to normal use (such as tires, brake pads, chains, spokes, freewheel, tire puncture, etc) are not included in the warranty but may be replaced on a case-by-case basis within the first 6 months.
  • Our bikes are water resistant but not waterproof. Water damage is not covered under warranty.


About NCM

NCM Bikes, founded in 2014, has quickly become one of the largest pedelec and e-bike brands in Europe with the goal of expanding the market significantly in the near future. NCM is the perfect brand to start your pedelec experience whether you are an avid cyclist or a relative newcomer, we are committed to providing you with a range of high quality. Our innovative technologies ensure that we can differentiate ourselves from the competition and continue to offer the latest technologies. Our goal is to help improve the environment through a friendly riding experience and the promotion of a fun and active lifestyle.


Notes

In order to ensure our high quality standard, our bicycles are subjected to a functional test at the factory. This can lead to dust deposits on the tyres and the seat post. Our bikes are only delivered pre-assembled, a final fine adjustment and inspection by the buyer or a third party is necessary (costs incurred for this cannot be covered). Before riding, please check all screws for strength and carry out a fine adjustment of the gears and brakes. Check the tyre pressure. For more information contact us on 0390695443. Visit our Youtube channel for Assembly and New Arrivals Videos. Depending on the bicycle model, the final assembly and inspection of the components should take between 60 and 90 minutes.

Our E-Bikes meet the following standards:

EPAC EN15194 (limited to 25km/h, 250W motor)
Chargers registered with Australian ERAC as approved for use in AU
Batteries meet international standards IEC 62133-2:2017 (inc battery management)

IMPORTANT NOTICE:
The laws around the use of scooters/e-bikes on public lands, roads and areas vary from state to state.
We recommend you always check your local council and road traffic laws prior to using a scooter/e-bike to ensure you are aware of any restrictions that may affect the use of motorised vehicles.
Always use appropriate protective riding equipment such as an approved helmet and suitable clothing.

Certain bike components such as tyres may change based on supplier availability, but all replacements will be of the same quality.

In the box

  • 1 x NCM M7 E-Bike
  • 1 x DK483 48V charger
  • 1 x tool kit


(P-Moscow-M7)

SKU P-Moscow-M7
Brand NCM
Shipping Weight 34.0000kg
Shipping Width 0.230m
Shipping Height 1.090m
Shipping Length 1.780m
Shipping Cubic 0.446246000m3
Unit Of Measure ea
